Shacman Tow Tractor Vehicle Truck for Daily Life Building Mining Cargo Transport

Basic Properties

Place of Origin: SHAANXI,XIAN

Brand Name: SHACMAN

Trading Properties

Minimum Order Quantity: 1

Price: Negotiable

Tractor Towing Truck

Specifications

Model NO.:	Shacman X5000 Tractor Truck	Transmission Type:	Manual
Power:	Diesel	Load Capacity:	21-30t
Emission Standard:	Euro 5	Drive Wheel:	6×4
Seats:	≤5	Horsepower:	＞450hp
Engine Capacity:	＞8L	Tire Certification:	ECE, GCC, ISO, DOT
Tire Design:	Tubeless	Condition:	New
Driver Position:	Left Hand	Color:	Enamel Red/Aurora White
Driving Type:	6*4	Wheelbase(mm):	3200+1400
Engines:	Weichai	Transport Package:	Roll
Specification:	819325403410	Trademark:	SHACMAN
Origin:	China	HS Code:	87042240
Production Capacity:	10000pieces/Year
High Light:	Shacman tow tractor truck , mining cargo transport vehicle , building transport tractor truck

Product Description

Shacman Heavy Duty Tow Tractor Vehicle

Professional dump truck designed for construction waste, sand, gravel, and cargo transport applications across building, mining, and daily life operations.

Shacman Tow Tractor Vehicle Truck for Daily Life Building Mining Cargo Transport 0

Product Overview

A dump truck featuring an elevated front-end box design for efficient material dumping. SHACMAN offers 5 series (X3000, F3000, H3000, F2000, L3000) to meet diverse customer requirements with configurations ranging from standard tippers to specialized vehicles for demanding applications.

Technical Specifications

Model	SX42584V324
Driver Position	Left Hand
Cabin	X5000 Extended High Roof Cab with Roof Side Deflectors
Color	Enamel Red/Aurora White
Driving Type	6×4
Wheelbase	3200+1400 mm
Engine Brand	WEICHAI
Engine Model	WP13.550E501
Emission Standard	EURO V
Rated Output Power	550 PS
Displacement	12.54L
Transmission Brand	FAST
Transmission Model	12JSDX240TA-QH50
Front Axle	HANDE MAN9.5T
Rear Axle	HANDE 16T MAN double reduction driving axle
Speed Ratio	5.262 enamel red/4.769 aurora white
Clutch	¢430 diaphragm clutch
Steering	ZF technology/ZF
Frame	850×300(8+5)
Suspension	Front and rear multi-plate springs
Wheels and Tires	12.00R20(10+1)
Oil Tank	600L+230L Aluminium alloy fuel tank

Braking System

Running Brake: Dual circuit compressed air brake
Parking Brake: Air discharging with spring control
Auxiliary Brake: Engine exhaust brake

Additional Features

Electronically controlled automatic climate control, cast 90 saddle, domestic clutch, DC air filter, common exhaust, domestic steering gear, 180Ah maintenance-free battery, electric flip, three-stage on-board pedals, FRP bumper, electric window rollers, central locking with remote control, air main seat, electric heated mirrors, four-point air suspension, multi-function steering wheel with cruise control, anti-flying splash wingboards, sunshade decorative lamps, side tool box, aluminium alloy air storage tank, front lower protection, aluminium alloy side protection bar, 2kg extinguisher, cab soundproof panel, aluminium alloy operating platform, parking wedge, mechanical fuel tank changeover valve, daytime running lights, 10-inch multi-media display, 360 surround view, cryogenic piping, ETA circuit breaker.

Customization Options

Engine

Weichai or Cummins options available. Weichai offers strong power and maintainability, while Cummins provides superior performance.

Gearbox

FAST manual or EATON ATM transmission systems.

Lifting System

HYVA or Chinese brand lifting mechanisms.

Dumper Size

Customizable height and thickness dimensions.

Cab

F3000, H3000, or X3000 series options. X3000 premium, F3000 popular, H3000 economical.

Tire & Oil Tank

Fully customizable tire specifications and oil tank configurations.

Color Options

White, Red, Orange, Green, Blue color selections.

Additional Spares

Camera systems, daylight running lights, and other accessories.

Manufacturer Profile

Shacman Tow Tractor Vehicle Truck for Daily Life Building Mining Cargo Transport 1

Shaanxi Hexin Shenghua Trading Co., Ltd is a global export authorized enterprise of Shaanxi Automobile heavy truck and the largest export authorized enterprise in SHACMAN heavy truck sales and service. Specializing in vehicle production customization services with 20 years of professional foreign trade experience.

Established on September 20, 2019, the company focuses on integrated export of Shaanxi Automobile heavy trucks, construction machinery, and special vehicles. With international presence in Uzbekistan, Tajikistan, Kyrgyzstan, Vietnam and other countries, serving markets across Central Asia, Africa, Asia-Pacific, and Central/South America.
