The F3000 6X4 tractor truck is the workhorse prime mover in the Shacman range. This SX4255JT324 build uses the 380HP Weichai WP10.380E22 engine with a FAST 12JSD200T-B twelve speed gearbox, a mechanical combination that keeps maintenance simple and parts easy to find in Central Asia, Africa and South America.
With 9.596 litres of displacement and a 90 km/h top speed, the unit is set up for container, flatbed and bulk trailer work on regional and long distance routes. A 400 L aluminium fuel tank and a 90 saddle are part of the standard build.
Technical specification| Model | SX4255JT324 |
|---|---|
| Driving type | 6x4 |
| Wheelbase | 3175 + 1400 mm |
| Max. speed | 90 km/h |
| Engine brand | Weichai |
| Engine model | WP10.380E22 |
| Emission standard | Euro 2 |
| Rated output | 380 HP |
| Displacement | 9.596 L |
| Transmission | FAST 12JSD200T-B |
| Front axle | HANDE MAN 7.5 T |
| Rear axle | HANDE 13 T MAN twin stage, ratio 4.769 |
| Clutch | 430 mm diaphragm clutch |
| Steering | ZF technology |
| Frame | 850 x 300 (8+5) mm |
| Suspension | Front and rear multi leaf spring |
| Fuel tank | 400 L aluminium alloy |
| Tyres | 12.00R20 |
| Brakes | Dual circuit air brake, spring parking, engine exhaust brake |
| Cab | F3000 cab, air master seat, air conditioning, 90 saddle |
Engine can be specified as Weichai or Cummins, cab colour and tyre brand are selectable, and options such as reversing camera, daytime running lights and a spare wheel carrier can be added to the build.
Send us your trailer type, typical payload and route profile and we will confirm the matching axle ratio, lead time and shipping arrangement.
