Shacman H3000 6*4 Water Tank Truck 18-20M³ Drinking Water Sprinkler Water Drilling Truck 400Hp
Basic Properties
Place of Origin:
SHAANXI,XIAN
Brand Name:
SHACMAN
Trading Properties
Minimum Order Quantity:
1
Price:
Negotiable
Specifications
| Storage: | Water Tank | Video outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Core Components: | Engine, Gearbox, PLC, Bearing, Motor, Pressure Vessel, Gear |
| Drive Wheel: | 6X4 | Fuel: | Diesel |
| Transmission Type: | Manual | Sprinkling Area (m): | > 16 M |
| Emission Standard: | Euro 2 | Engine Capacity: | > 8L |
| Dimensions (L x W x H) (mm): | 8200x2500x3500mm | Gross Vehicle Weight: | 30000 |
| Warranty: | 1 Year | Weight (KG): | 20000 Kg |
| Engine: | WEICHAI, WP10.340E22, WP10.400E22 | Horsepower: | 340Hp,400 Hp |
| Vehicle Speed Ratio: | 13T HD Dual-stage 5.262 | Wheelbase: | 4375+1400mm |
| Frame: | 850x300(8+5)mm | Suspension: | Front And Rear Multi-leaf Spring, Two Main Plates + Two Horse Bolts |
| Tyre: | 12.00R20, 12R22.5 | Economy Speed/Maximum Speed: | 50~70/90km/h |
| Maximum Width of Watering: | ≥30m | Control Mode: | Automatic Control |
| High Light: | Shacman H3000 water tank truck,6x4 drinking water sprinkler truck,400HP water drilling truck |
||
Product Description
SHACMAN H3000 Series Water Sprinkler Trucks
The sprinkler truck, also known as a multi-functional sprinkler truck, is a special vehicle designed for road cleaning, environmental moisturizing, greening maintenance, and emergency operations. It is widely used in municipal sanitation, highway maintenance, landscaping, mining plants, and other scenarios.
Product Specifications
| Chassis System | |
|---|---|
| Driving Type | 6x4 (also available: 4x2, 8x4) |
| Wheelbase | 4375+1400mm |
| Max. Speed | 80km/h |
| Engine Brand | WEICHAI |
| Engine Model | WP10.340E22, WP10.400E22 |
| Horsepower | 340Hp/250kw, 400Hp/294kw |
| Emission Standard | EURO II |
| Front/Rear Axle | HANDE |
| Frame | 850x300(8+5)mm |
| Fuel Tank | 300L/400L Aluminum alloy |
| Tire | 12R22.5, 12.00R20 |
| Tank System | |
| Tank Volume | 20m³ |
| Tank Body Shape | Circular |
| Tank Material | 5mm (carbon steel) |
| Water Addition Method | Self suction/fire water supply/tank top |
| Sprinkler System | |
| Control Mode | Automatic control |
| Pipeline Diameter | Main pipeline 80mm, Auxiliary pipeline 50mm |
| Spraying Device | Forward flushing, Hedging, Rear sprinkler, Side spray, Green anti-aircraft gun |
| Max. Width of Watering | ≥30m |
| Max. Height of Water Cannon | ≥35m |
| Max. Water Absorption Height | ≥10m |
Available Models
L3000 4x2 Water Sprinkler Truck
X3000 6x4 Water Sprinkler Truck
F3000 6x4 Water Sprinkler Truck
About Our Company
Henan Senyao Heavy Truck International Trade Co., Ltd. is mainly engaged in the export integration of Shaanxi Automobile Heavy Truck, special vehicles and construction machinery, and is a global export authorization enterprise of Shaanxi Automobile Heavy Truck. We always adhere to the strategic policy of "mutual benefit, honesty and win-win", and build a huge sales network in Central Asia, Africa, Central and South America with excellent brand advantages and our own perfect procurement and supply system.
With an annual export capacity of more than 3,000 sets, Senyao's product quality and service have been well received by customers at home and abroad. Military quality, professional export, looking forward to long-term cooperation with you!
Shipping & Logistics
- Professional export packaging: Weather-proof and secure
- Multiple shipping methods: RORO, container, or bulk vessel
- Worldwide delivery: Experience in shipping to 50+ countries
- Documentation support: Complete export documentation provided
Frequently Asked Questions
What size sprinkler truck should I choose?
3-8 tons: Small water sprinkler trucks with high maneuverability, suitable for residential areas and narrow streets.
8-15 tons: Medium-sized water sprinkler trucks offering high cost-effectiveness, suitable for most urban roads.
15-20 tons and above: Large water sprinkler trucks suitable for long-distance highway maintenance and large industrial areas.
8-15 tons: Medium-sized water sprinkler trucks offering high cost-effectiveness, suitable for most urban roads.
15-20 tons and above: Large water sprinkler trucks suitable for long-distance highway maintenance and large industrial areas.
Can a sprinkler truck only be used for sprinkling water?
No, it has multiple functions including road washing, greening irrigation, emergency dust suppression, and some models can be equipped with spray devices for air purification or cooling.
Can the working range be adjusted?
Yes. Most sprinkler trucks are equipped with adjustable nozzles that can control sprinkling on one side, both sides, or specific areas. Water flow intensity can also be adjusted.
How much water can a sprinkler truck hold and how much area can it cover?
Conventional models range from 5 to 20 tons. A 10-ton truck operating at low speed (5-8 km/h) can cover 2-3 kilometers of road with one load of water.
Is the vehicle complicated to operate?
Very simple. All mainstream water trucks can be operated via electronic controls inside the cab without needing to get out.
What about after-sales service and warranty?
Chassis part follows the manufacturer's national warranty policy. The superstructure part (water tank, water pump, piping system) we provide an independent warranty service (usually 1-2 years).
Selection Guide
Step 1: Define Your Needs
Primary Purpose:
Urban road sprinkling, garden irrigation, emergency firefighting, dust control, or highway cleaning
Urban road sprinkling, garden irrigation, emergency firefighting, dust control, or highway cleaning
Tank Capacity:
5-8 tons for construction sites, 10 tons for circulation operations, 15+ tons for long-distance operations
5-8 tons for construction sites, 10 tons for circulation operations, 15+ tons for long-distance operations
Road Conditions:
Urban asphalt roads or unpaved construction sites requiring different chassis specifications
Urban asphalt roads or unpaved construction sites requiring different chassis specifications
Budget Range:
Prices range from over 100,000 RMB to several hundred thousand RMB depending on configuration
Prices range from over 100,000 RMB to several hundred thousand RMB depending on configuration
Water Source:
Hydrants, rivers, or ponds - determines required suction head of water pump
Hydrants, rivers, or ponds - determines required suction head of water pump
Step 2: Key Questions for Suppliers
Chassis & Powertrain:
Brand and model, engine horsepower, emission standards, wheelbase
Brand and model, engine horsepower, emission standards, wheelbase
Tank System:
Capacity, material, anti-corrosion treatment, water pump specifications
Capacity, material, anti-corrosion treatment, water pump specifications
Spraying System:
Suction head, sprinkling width, standard functions, practical configurations
Suction head, sprinkling width, standard functions, practical configurations
