Shacman Multi Type Water Splashing Sprinkler Vehicle Lorry Truck for Municipal Maintenance

Basic Properties

Place of Origin: SHAANXI,XIAN

Brand Name: SHACMAN

Certification: ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE

Trading Properties

Minimum Order Quantity: 1

Price: Negotiable

Shacman municipal sprinkler truck

multi type sprinkler vehicle

Specifications

Model NO.:	Shacman X3000 Sprinkler Truck	Volume:	Customize
Emission Standard:	Euro 2	Sprinkling Area:	Customize
Transmission Type:	Customize	Payload:	Customize
Fuel:	Diesel	Drive Wheel:	6×4
Engine Capacity:	＞8L	Condition:	New
Driving Type:	6×4	Wheelbase:	3975+1400
Max. Speed:	75km/H	Engine Brand:	Weichai
Rated Output Power:	380HP	Transport Package:	Wooden Transport
Specification:	7900mm2490mm3220mm	Trademark:	SHACMAN
Origin:	China	HS Code:	8705909990
Production Capacity:	1000
High Light:	Shacman municipal sprinkler truck , water splashing lorry truck , multi type sprinkler vehicle

Product Description

Shacman Multi Type Water Splashing Sprinkler Vehicle

Custom capacity water spraying sprinkler vehicle lorry truck designed for municipal engineering and maintenance applications.

Product Overview

A specialized dump truck featuring a front-elevating box system for efficient material dumping. Designed for hauling construction waste, sand, gravel, and similar materials in municipal and construction environments.

SHACMAN dump trucks are available in 5 series (X3000, F3000, H3000, F2000, L3000) to meet diverse customer requirements. With multiple configurations ranging from standard tippers to highly specialized vehicles for demanding applications, SHACMAN provides comprehensive solutions for all job requirements.

Technical Specifications

Parameter	Specification
Model	SX32555T404
Driver Position	Left Hand
Driving Type	6×4
Wheelbase	3975+1400
Max Speed	75km/h
Engine
Brand	WEICHAI
Model	WP10.380E22
Emission Standard	EURO 2
Rated Output Power	380HP
Transmission
Brand	FAST
Model	12JSD200T-B-Iron Shell-QH50
Axles
Front Axle Brand	HANDE
Front Axle Model	MAN 9.5T
Rear Axle Brand	HANDE
Rear Axle Model	16T MAN Double-Stage Reduction Drive Axle (Speed ratio: 5.262)
Additional Components
Clutch	¢430 diaphragm clutch
Steering	ZF technology/ZF
Frame	850×300(8+7)
Suspension	Front and rear multi-leaf spring (four main leaves + four horse riding)
Fuel Tank	400L Aluminum alloy fuel tank
Wheels and Tires	12.00R20 Radial Tyre (Tyre 20 ply Rating) 10+1

Braking System

Running Brake: Dual circuit compressed air brake
Parking Brake: Air discharging with spring control
Auxiliary Brake: Engine exhaust brake

Cab Features

X3000 extended flat roof cab without roof guide cover dump truck with comprehensive amenities including:

Electric automatic constant temperature air conditioning
Desert air filter and ordinary exhaust system
Multi-leaf spring front and rear suspension
Domestic steering gear with multifunctional steering wheel
165Ah maintenance-free battery
Electric flip mechanism and three-level boarding pedal
Metal bumper with light protection net
Center front traction seat and air main seat
Electric window system and central locking with remote control
Electric heated rearview mirrors
Comprehensive safety features including tail light protection grille, water tank protection grille, and 2KG fire extinguisher

Upbody Specifications

Large box size: 5800 × 2300 × 1500
Bottom plate thickness: 10mm
Edge plate thickness: 8mm
Box color: Matches cab color
Additional components: Tianzi grid and T700 high-strength board

Customization Options

Engine Selection

Available options include Weichai and Cummins engines. Weichai offers strong power and easier maintenance, while Cummins provides superior performance with specialized maintenance requirements.

Transmission Options

Choose between FAST manual transmission and EATON ATM automatic transmission systems.

Lifting System

HYVA or Chinese brand lifting systems available to suit different operational requirements and budget considerations.

Dumper Size Customization

Height and thickness modifications available to accommodate specific load requirements and operational conditions.

Cab Series

Multiple cab series available: X3000 (premium), F3000 (most popular), and H3000 (economical option). Contact us for detailed comparisons.

Additional Customizations

Tire specifications tailored to operational requirements
Oil tank capacity and configuration adjustments
Color options: White, Red, Orange, Green, Blue
Additional spares: Camera systems, daylight running lights, and other accessories
