Shacman F3000 8X4 13 Wheels Lorry-Mounted Crane
| Model NO.: | SX5315JSQDT456 | Engine: | Commins Or Weichai |
| Commins: | USA Brand | Fuel Tank/: | 300L |
| Frame/: | 850X300(8+5+8) | Transport Package: | Roll-Roll |
| Specification: | 45cbm | Trademark: | Shacman |
| Origin: | China | HS Code: | 870590 |
| Production Capacity: | 800PCS/Per Day | ||
| High Light: | Shacman F3000 lorry-mounted crane,8X4 cement mixer truck,13 wheels heavy-duty crane |
||
| Model | SX5315JSQDT456 |
|---|---|
| Driver Position | Left Hand |
| Driving Type | 8×4 |
| Wheelbase | 2100+4575+1400 mm |
| Maximum Speed | 90 km/h |
| Fuel Tank Capacity | 300L |
| Brand | WEICHAI |
|---|---|
| Model | WP10.380E22 |
| Emission Standard | EURO II |
| Rated Output Power | 279KW / 380HP |
| Displacement | 9.726L |
| Transmission Brand | FAST |
|---|---|
| Transmission Model | 10JSD180+QH50 |
| Front Axle | HANDE 9.5T |
| Rear Axle | HANDE 16T MAN double reduction driving axle |
| Clutch | ¢430 diaphragm clutch |
| Steering | ZF technology |
| Frame | 850×300 (8+5+8) |
|---|---|
| Suspension | Front and rear multi-leaf |
| Wheels and Tires | 12.00R20 12+1 |
- Foldable with sleeper
- Air-conditioned electric window
- Hydraulic main seat
- Four point hydraulic suspension cab
- Electric window lifter
- Manual flipping
- Electric air conditioning
- Telescopic shaft control
- Ordinary air filter
- Metal bumper
- Two-stage boarding pedal
- 165Ah maintenance free battery
- SHACMAN logo, all English logo
- M cab (flat top)
| Dimensions | 8000×2400×550 mm |
|---|---|
| Edge Plate | 3mm |
| Bottom Plate | 5mm |
| Maximum Torque | 333 kN.m |
|---|---|
| Lifting Capacity | 15T (16.5) |
| Boom Length | 12m / 15m / 13m |
| Working Angle | 0°-75° |
| Rotation | 360° |
| Working Radius | 2.34-7.78m |
