Shacman Concrete Beton Stir Mixer Vehicle Truck For Construction Project

Basic Properties

Place of Origin: SHAANXI,XIAN

Brand Name: SHACMAN

Certification: CCC, CE, GOST, ISO, SONCAP

Trading Properties

Minimum Order Quantity: 1

Price: Negotiable

special transport truck with warranty

Customized Tow X3000 8X4 wrecker truck

refrigeration box delivery van

Specifications

Model NO.:	Shacman X3000 Mixer	Capacity:	Customize
Condition:	New	Main Material:	Alloy Steel, Stainless Steel
Mixing Capacity:	Customize	Mixing Drum Shape:	Customize
Power Source:	Diesel	Safety Features:	Anti-Slip Feet, Emergency Stop Button, Overload Protection, Safety Lock, Splash Guard
Stirring Type:	Customize	Warranty:	24hr Hotline
Working:	Customize	Driving Type:	6×4
Wheelbase:	3975+1400	Max. Speed:	75km/H
Engine Brand:	Weichai	Rated Output Power:	380HP
Transport Package:	Wooden Transport	Specification:	7900mm2490mm3220mm
Trademark:	SHACMAN	Origin:	China
HS Code:	8704230090	Production Capacity:	1500pieces/Year
High Light:	Shacman concrete mixer truck , construction beton mixer vehicle , cement mixer truck for construction

Product Description

Shacman Concrete Mixer Truck for Construction Projects

Factory direct sale Shacman concrete mixing lorry truck engineered for demanding construction and engineering projects.

Shacman Concrete Beton Stir Mixer Vehicle Truck For Construction Project 0

Product Overview

A dump truck features an elevated front-end box that allows contents to be dumped from the rear. These trucks are specifically designed for transporting construction materials including waste, sand, gravel, and similar aggregates.

SHACMAN dump trucks offer five distinct series - X3000, F3000, H3000, F2000, and L3000 - to accommodate diverse customer requirements. With multiple configurations available, from standard tippers to specialized vehicles for challenging applications, SHACMAN provides comprehensive solutions for any construction need.

Technical Specifications

Parameter	Specification
Model	SX32555T404
Driver Position	Left Hand
Driving Type	6×4
Wheelbase	3975+1400
Maximum Speed	75km/h
Engine
Brand	WEICHAI
Model	WP10.380E22
Emission Standard	EURO 2
Rated Output Power	380HP
Transmission
Brand	FAST
Model	12JSD200T-B-Iron Shell-QH50
Axles
Front Axle	HANDE MAN 9.5T
Rear Axle	HANDE 16T MAN Double-Stage Reduction Drive Axle (Speed ratio: 5.262)
Clutch	¢430 diaphragm clutch
Steering	ZF technology/ZF
Frame	850×300(8+7)
Suspension	Front and rear multi-leaf spring (four main leaves + four horse riding)
Fuel Tank	400L Aluminum alloy fuel tank
Wheels and Tires	12.00R20 Radial Tire (Tire 20 ply Rating) 10+1
Brakes	Running brake: Dual circuit compressed air brake Parking brake: Air discharging with spring control Auxiliary brake: Engine exhaust brake

Cab Features

X3000 extended flat roof cab without roof guide cover dump truck
Electric automatic constant temperature air conditioning
Desert air filter and ordinary exhaust system
Multi-leaf spring front and rear suspension
Domestic steering gear with multifunctional steering wheel
165Ah maintenance-free battery
Electric flip and three-level boarding pedal
Metal bumper with light protection net
Center front traction seat
Electric window mechanism and central locking with remote control
Air main seat and electric heated rearview mirror
Tail light protection grille and water tank protection grille
Front stabilizer bar and four-point hydraulic suspension
Stainless steel wheel rim decoration cover
Reverse buzzer and daytime running lights
SHACMAN logo and full English branding
2KG fire extinguisher and parking wedge block
Rear axle stabilizer bar and battery box anti-theft system

Upbody Specifications

Large box size: 5800 × 2300 × 1500
Bottom plate thickness: 10mm
Edge plate thickness: 8mm
Large box color: Matches cab color
Additional components: Tianzi grid and T700 high-strength board

Customization Options

Engine: Available in Weichai or Cummins. Cummins offers superior performance but requires specialized maintenance. Weichai provides strong power with easier maintenance accessibility.

Gearbox: Options include FAST manual transmission or EATON ATM automatic transmission.

Lifting System: Choose between HYVA or Chinese brand lifting mechanisms.

Dumper Size: Customizable height and thickness dimensions available.

Cab: Available in F3000, H3000, or X3000 series. X3000 offers premium features, F3000 is the most popular, and H3000 provides cost-effective solutions.

Tire: Fully customizable tire specifications.

Oil Tank: Customizable fuel tank configurations.

Color: Available in White, Red, Orange, Green, or Blue.

Additional Spares: Optional accessories including cameras, daylight running lights, and other specialized equipment.

Manufacturer Profile

Shacman Concrete Beton Stir Mixer Vehicle Truck For Construction Project 1

Shaanxi Hexin Shenghua Trading Co., Ltd is a globally authorized export enterprise of Shaanxi Automobile heavy trucks. As the largest export authorized enterprise in SHACMAN heavy truck sales and service networks, our core business focuses on vehicle production customization services.

Our development philosophy centers on professionalism, innovation, and long-term vision, with 20 years of specialized foreign trade experience. Established on September 20, 2019, we specialize in the integrated export of Shaanxi Automobile heavy trucks, construction machinery, and special vehicles.

Continuing the legacy of Silk Road commerce, we actively expand international and domestic markets with established companies and sales outlets in Uzbekistan, Tajikistan, Kyrgyzstan, Vietnam, and other countries through strategic partnerships. Our foreign trade operations extend across Central Asia, Africa, Asia-Pacific, Central and South America, forming a comprehensive international export circulation system.
