HACMAN X5000 Lightweight Edition 6×4 Tractor Truck | 480HP Euro V | For Heavy Load Transport
Basic Properties
Place of Origin:
SHAANXI,XIAN
Brand Name:
SHACMAN
Model Number:
SX42584V324
Trading Properties
Minimum Order Quantity:
1
Price:
Negotiable
Specifications
| Model NO.: | Shacman X5000 Tractor Truck | Transmission Type: | Manual |
| Power: | Diesel | Load Capacity: | 21-30t |
| Emission Standard: | Euro 5 | Drive Wheel: | 6×4 |
| Seats: | ≤5 | Horsepower: | ＞450hp |
| Engine Capacity: | ＞8L | Tire Certification: | ECE, GCC, ISO, DOT |
| Tire Design: | Tubeless | Condition: | New |
| Driver Position: | Left Hand | Color: | Enamel Red/Aurora White |
| High Light: | SHACMAN X5000 6x4 tractor truck,480HP Euro V heavy duty truck,enhanced edition tractor truck with warranty |
||
Product Description
SHACMAN X5000 Enhanced Edition 6*4 Tractor Truck
480HP Euro V Heavy Duty Transport Vehicle
Shacman Heavy Duty water oil cargo transport trailer tractor tipper dump truck
Product Overview
A dump truck features a front-elevating box that allows contents to be dumped from the rear. Designed for transporting construction waste, sand, gravel, and similar materials, SHACMAN dump trucks offer five series (X3000, F3000, H3000, F2000, L3000) to meet diverse customer requirements.
With configurations ranging from standard tippers to specialized vehicles for demanding applications, SHACMAN provides comprehensive solutions for any job. Our qualified professionals assist in selecting the perfect vehicle for your specific needs.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | SX42584V324 |
| Driver Position | Left Hand |
| Cabin | X5000 Extended High Roof Cab with Roof Side Deflectors |
| Color | Enamel Red/Aurora White |
| Driving Type | 6*4 |
| Wheelbase | 3200+1400 mm |
| Engine Brand | WEICHAI |
| Engine Model | WP13.550E501 |
| Emission Standard | EURO V |
| Rated Output Power | 550 PS |
| Displacement | 12.54L |
| Transmission Brand | FAST |
| Transmission Model | 12JSDX240TA-QH50 |
| Front Axle | HANDE MAN9.5T |
| Rear Axle | HANDE 16T MAN double reduction driving axle |
| Speed Ratio | 5.262 enamel red/4.769 aurora white |
| Clutch | ¢430 diaphragm clutch |
| Steering | ZF technology |
| Frame | 850*300(8+5) |
| Suspension | Front and rear multi-plate springs |
| Wheels and Tires | 12.00R20(10+1) |
| Oil Tank | 600L+230L Aluminium alloy fuel tank |
Braking System
- Running brake: Dual circuit compressed air brake
- Parking brake: Air discharging with spring control
- Auxiliary brake: Engine exhaust brake
Additional Features
Electronically controlled automatic climate control, cast 90 saddle, domestic clutch, DC air filter, common exhaust, domestic steering gear, 180Ah maintenance-free battery, electric flip, three-stage on-board pedals, FRP bumper, electric window rollers, central locking with remote control, air main seat, electric heated mirrors, four-point air suspension, multi-function steering wheel with cruise control, anti-flying splash wingboards, sunshade decorative lamps, side tool box, aluminium alloy air storage tank, front lower protection, aluminium alloy side protection bar, 2kg fire extinguisher, parking wedge, mechanical fuel tank changeover valve, daytime running lights, 10-inch multi-media display, 360 surround view, cryogenic piping, ETA circuit breaker.
Customization Options
- Engine: Weichai or Cummins. Cummins offers superior performance but limited maintenance accessibility. Weichai provides strong power with better maintenance support.
- Gearbox: FAST manual or EATON ATM transmission systems
- Lifting System: HYVA or Chinese brand lifting mechanisms
- Dumper Size: Customizable height and thickness dimensions
- Cab: F3000, H3000, or X3000 series (X3000 premium, F3000 popular, H3000 economical)
- Tire: Custom tire specifications available
- Oil Tank: Custom fuel tank configurations
- Color: White, Red, Orange, Green, Blue color options
- Spares: Additional accessories including cameras, daylight systems, etc.
Manufacturer Profile
Shaanxi Hexin Shenghua Trading Co., Ltd is a global export authorized enterprise of Shaanxi Automobile heavy truck. As the largest export authorized enterprise in SHACMAN heavy truck sales and service, we specialize in vehicle production customization services.
With 20 years of professional foreign trade experience, our company focuses on the integration of Shaanxi Automobile heavy trucks, construction machinery, and special vehicles for export. Established on September 20, 2019, we continue the Silk Road business tradition, expanding internationally with companies and sales outlets in Uzbekistan, Tajikistan, Kyrgyzstan, Vietnam, and other countries.
Our foreign trade business extends across Central Asia, Africa, Asia-Pacific, Central and South America, forming a comprehensive export circulation system.
Product Gallery
Last updated: 2025-05-10
