| Brand Name: | SHACMAN |
| MOQ: | 1 |
| Price: | Negotiable |
| Delivery Time: | 35-55days |
| MODEL | SX3255JM384 |
| Driver position | Left Hand |
| Driving type | 6×4 |
| Wheelbase | 3775+1400 |
| Max. Speed | 65km/h |
| Engine | |
| Brand | Weichai |
| Model | WP10.290E32 |
| Emission Standard | EURO2 |
| Rated output power | 290 PS |
| Displacement | 9.726L |
| Transmission | |
| Brand | FAST |
| Model | 9JS135-iron hell-QH50 |
| Front Axle | |
| Brand | HANDE |
| Model | MAN7.5T |
| Rear Axle | |
| Brand | HANDE |
| Model | 16T MAN Twin-Stage Cast Axle 5.73 |
| Steering | ZF technology/ZF |
| Frame | 850×300(8+7) |
| Suspension | Front and rear multi-leaf spring two main plates + two riding bolts |
| Fuel tank | 380L iron tank |
| Wheels and tires | 12R22.5(10+1) |
| Brakes | |
| Running brake | Dual circuit compressed air brake |
| Parking brake | Air discharging with spring control |
| Auxiliary brake | Engine exhaust brake |
| Cabin | |
| Configuration | F2000 extended flat roof cab without top deflector tipper truck, hot zone air-conditioner, manual window crank, hydraulic main seat, single sleeper, single rear view mirror, imported clutch, common side air filter, domestic steering gear, common steering wheel, domestic six-channel ABS, domestic tachograph, 165Ah maintenance-free battery, manual flip, fixed on-board pedals, fibreglass bumper |
| Upbody | |
| Box Size | 5200×2300×1350 |
| Baseplate thickness | 8 |
| Bangboard thickness | 6 U type container |
