Litter Rubbish Garbage Collecting Compressing Cleaning Vehicle Lorry Truck

Basic Properties

Place of Origin: SHAANXI,XIAN

Brand Name: SHACMAN

Certification: ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE

Trading Properties

Minimum Order Quantity: 1

Price: Negotiable

waste compressing vehicle

Specifications

Model NO.:	L3000 Garbage Truck	Type:	Garbage Truck
Volume:	Customize	Emission Standard:	Euro 5
Transmission Type:	Manual	Payload:	Customize
Fuel:	Diesel	Drive Wheel:	Customize
Brand:	Shacman	Models:	Customize
Usage:	Dump, Compression Type, Garbage Truck	Condition:	New
Engine:	Wp6.210e32	Transmission:	8js85te-C(Alumnium)
Front Axle:	4.8t (Disc Brake)	Rear Axle:	10t Single-Stage Bridge 4.625
Fuel Tank:	200L Iron Fuel Tank	Suspention:	Front And Rear Multiple Leaf Springs, Four Main P
Wheels:	10.00r20	Wheelbase(mm):	5000mm
Frame(mm):	870mm X 250mm 7+4	Cabin:	L3000 Cab
Model:	Sx1255mn464	Battery:	135 Maintenance-Free Battery
Transport Package:	Roll -Roll	Trademark:	Shacman
Origin:	China	HS Code:	8705909990
Production Capacity:	1000
High Light:	garbage compactor truck , rubbish collecting lorry , waste compressing vehicle

Product Description

Shacman Garbage Compressing Collection Truck

High-performance Shacman diesel engine rubbish garbage collection and compression processing lorry truck designed for efficient waste management operations.

Litter Rubbish Garbage Collecting Compressing Cleaning Vehicle Lorry Truck 0

Product Overview

A specialized dump truck featuring an elevated front-end box for efficient waste dumping. Designed for construction waste, sand, gravel, and similar materials transportation and disposal.

SHACMAN dump trucks include 5 series (X3000, F3000, H3000, F2000, L3000) to meet diverse customer requirements. Available in multiple configurations from standard tippers to specialized vehicles for demanding applications.

Technical Specifications

Chassis Parameters

Drive Type	4X2
Wheelbase	4500/5000 mm

Compression Box Specifications

Effective Volume	16m³
Box Shape	Curved/square box body
Box Material	Q355 High-strength Steel
Edge Plate Thickness	5mm
Bottom Plate Thickness	5mm
Compression Ratio	≥2.5
Sewage Tank Capacity	300L / 500L (Front/Rear)
Filler Effective Volume	≥1.8m³
Filler Slide Material	T420 High-strength Steel/8mm

Performance Metrics

Filling Cycle Time	≤25s
Filling Machine Lifting Time	≤15s
Unload Garbage Time	≤45s
Maximum Flipping Capacity	≤500kg
Flipping Mechanism Working Time	≤12s

Control Systems

Control Mode	Automatic + Manual + Wireless Remote Control
Control System	CAN-BUS Bus Control
Engine Power Control	Fully Automatic Control
Electronic Control System	CAN-BUS + Silicone Button Control Box

Hydraulic System

Hydraulic System Pressure	18MPa
Multi-way Directional Valve	Yangzhou Zhongmei
Hydraulic Oil Pump	Hefei Changyuan Pump
Lift Cylinder Balance Valve	Yangzhou Zhongmei (Optional Imported)
Hydraulic Cylinder	Hunan Juge Oil Cylinder
Tubing	3-layer Steel Wire Hose

Flipping System Options

Bucket Flipping Mechanism	Rear Tail with Bucket Flipping
Bucket Flipping Type	120/240/660/1100 L Drum
Option 1	Triangle Bucket
Option 2	Full Floor Bucket
Option 3	Swing Arm Device

Customization Options

Engine: Weichai or Cummins options available

Gearbox: FAST manual or EATON ATM

Lifting System: HYVA or Chinese brand options

Dumper Size: Customizable height and thickness

Cab: F3000, H3000, or X3000 series

Tire: Fully customizable

Oil Tank: Customizable specifications

Color: White, Red, Orange, Green, Blue

Spares: Camera, daylight sensors, and additional accessories

Service & Support

Delivery Time: Chassis delivery within 15 working days

Vehicle After-sales Service: 18 months comprehensive warranty
