Shacman Box Fence Cargo/Concrete Mixing Tractor Tipper Dump Truck
Basic Properties
Place of Origin:
SHAANXI,XIAN
Brand Name:
SHACMAN
Trading Properties
Minimum Order Quantity:
1
Price:
Negotiable
Specifications
| Model NO.: | SHACMAN F2000 | Transmission Type: | Automatic |
| Power: | Diesel | Load Capacity: | 21-30t |
| Emission Standard: | Euro 2 | Drive Wheel: | 6×4 |
| Engine Capacity: | ＞8L | Seats: | ≤5 |
| Horsepower: | 351-450hp | Tire Certification: | ECE, GCC |
| Tire Design: | Tubeless | Dumping Type: | Side Dumping Style |
| Condition: | New | Model: | Sx3255jm384 |
| Driver Position: | Left Hand | Wheel Base: | 3775+1400 |
| Max. Speed: | 65km/H | Engine: | Weichai |
| Emission Standard/: | Euro2 | Displacement (L): | 9.726L |
| Fuel Tank: | 380L Iron Tank | Wheels Tires: | 12r22.5(10+1) |
| Transport Package: | Wooden Transport | Specification: | 7900mm*2490mm*3220mm |
| Trademark: | SHACMAN | Origin: | China |
| HS Code: | 87042391 | Production Capacity: | 800PCS/Per Day |
| High Light: | Shacman box fence dump truck,concrete mixing tractor tipper,compactor garbage truck with warranty |
||
Product Description
Shacman Box Fence Cargo/Concrete Mixing Tractor Tipper Dump Truck
High performance SHACMAN F2000 6×4 driving type LHD cargo dump truck
Product Overview
A dump truck is designed with a front-elevating box to efficiently discharge contents from the rear. These vehicles are ideal for transporting construction materials including waste, sand, gravel, and similar bulk items.
SHACMAN offers five comprehensive dump truck series—X3000, F3000, H3000, F2000, and L3000—to meet diverse operational requirements. From standard tippers to specialized vehicles for demanding applications, SHACMAN provides reliable solutions tailored to your specific needs.
Technical Specifications
| MODEL | SX3255JM384 |
| Driver position | Left Hand |
| Driving type | 6×4 |
| Wheelbase | 3775+1400 |
| Max. Speed | 65km/h |
| Engine | |
| Brand | Weichai |
| Model | WP10.290E32 |
| Emission Standard | EURO2 |
| Rated output power(PS) | 290 |
| Displacement(L) | 9.726L |
| Transmission | |
| Brand | FAST |
| Model | 9JS135-iron hell-QH50 |
| Front Axle | |
| Brand | HANDE |
| Model | MAN7.5T |
| Rear Axle | |
| Brand | HANDE |
| Model | 16T MAN Twin-Stage Cast Axle5.73 |
| Steering | ZF technology/ZF |
| Frame | 850×300(8+7) |
| Suspension | Front and rear multi-blade spring two main plates + two Riding Bolts |
| Fuel tank | 380L iron tank |
| Wheels and tires | 12R22.5(10+1) |
| Brakes | Running brake: Dual circuit compressed air brake Parking brake: Air discharging with spring control Auxiliary brake: Engine exhaust brake |
| Cabin | F2000 extended flat roof cab without top deflector tipper truck/hot zone air-conditioner/manual window crank/hydraulic main seat/single sleeper/single rear view mirror/imported clutch/common side air filter/domestic steering gear/common steering wheel/domestic six-channel ABS/domestic tachograph/165Ah maintenance-free battery/manual flip/fixed on-board pedals/fibreglass bumper |
| Upbody | Box Size: 5200x2300x1350 Baseplate thickness: 8 Bangboard thickness: 6 U type container |
Customization Options
Engine
Available with Weichai or Cummins engines. Cummins offers superior performance but requires specialized maintenance. Weichai provides strong power with easier maintenance accessibility.
Gearbox
Options include FAST manual transmission or EATON ATM automatic transmission.
Lifting System
Choose between HYVA or Chinese brand lifting mechanisms.
Dumper Size
Customizable height and thickness dimensions available.
Cab
Multiple cab options: F3000 (most popular), H3000 (most economical), X3000 (premium). Contact us for detailed comparisons.
Tire
Custom tire specifications available.
Oil Tank
Custom fuel tank configurations.
Color
Available in White, Red, Orange, Green, and Blue.
Spares
Additional accessories including cameras, daylight running lights, and more.
Manufacturer Profile
Shaanxi Hexin Shenghua Trading Co., Ltd
As an authorized global export enterprise of Shaanxi Automobile heavy truck, we are the largest export authorized entity for SHACMAN heavy truck sales and service worldwide. Our core specialization is vehicle production customization services.
With 20 years of professional foreign trade experience, our company was established on September 20, 2019, focusing on the integrated export of Shaanxi Automobile heavy trucks, construction machinery, and special vehicles.
Continuing the legacy of Silk Road commerce, we actively expand international markets with established operations in Uzbekistan, Tajikistan, Kyrgyzstan, Vietnam, and other countries. Our global trade network extends across Central Asia, Africa, Asia-Pacific, and Central/South America, creating a comprehensive foreign trade export system.
Global Cooperation
