| Brand Name: | Shacman |
| Model Number: | DZ91189523010 |
| MOQ: | 1 |
| Price: | Negotiable |
| Delivery Time: | 2-5 days sample / 15-25 days bulk |
| Payment Terms: | T/T,L/C at sight |
OE-Grade Quality: Precision-engineered to original SHACMAN specifications with premium organic non-asbestos friction compound. 430mm OD, 10-spline forged steel hub with multi-spring torsional damper. Rated 100,000+ km service life under normal operating conditions.
| # | Advantage | Detail |
|---|---|---|
| 1 | OE-Grade Precision Fit | Manufactured to original SHACMAN dimensional tolerances — spline, diameter, and thickness perfectly matched for bolt-on installation |
| 2 | High-Heat Endurance | Organic non-asbestos composite friction material with engineered heat dissipation grooves, stable performance under continuous heavy-load start-stop conditions |
| 3 | Permanent Warehouse Stock | All popular SHACMAN clutch disc models stocked in depth — same-day dispatch, no backorder delays |
| 4 | OEM & Private Label Ready | Accept custom logo laser marking, branded packaging design, and private-label box printing for authorized distributors worldwide |
| 5 | 12-Month / 100,000 KM Warranty | Full coverage against friction material delamination, spring failure, and hub spline defect — free replacement guaranteed |
| Parameter | Specification |
|---|---|
| Part Number | DZ91189523010 |
| Friction Material | Organic Non-Asbestos Composite (NAO) |
| Outer Diameter | 430mm |
| Inner Diameter | 240mm |
| Spline Count | 10-Spline |
| Hub Material | Forged 45# Carbon Steel, Heat-Treated |
| Torsion Damper | Multi-Spring Damped Hub |
| Net Weight | 6.8 kg |
| MOQ | 1 pc (sample) / 50 pcs (bulk) |
| Brand | Series | Vehicle Type |
|---|---|---|
| SHACMAN | X3000 | Tractor Truck / Dump Truck / Concrete Mixer |
| SHACMAN | F3000 | Heavy Tipper / Long-Haul Tractor |
| SHACMAN | H3000 | Dump Truck / Cargo Truck / Mixer Truck |
The clutch disc friction facing is composed of a premium organic non-asbestos (NAO) composite reinforced with aramid fiber and mineral fillers, hot-pressed under 200-ton hydraulic pressure onto a high-tensile steel core plate. The hub is drop-forged from 45# medium-carbon structural steel, CNC-machined to exact spline geometry, then induction-hardened at the tooth contact surface to HRC 48-52. Each disc undergoes dynamic balance testing at 4,000 RPM, thickness parallelism inspection, rivet pull-out force testing, and friction coefficient verification on a full-size inertia dynamometer.
| Tier | Quantity | Benefit |
|---|---|---|
| Sample Order | 1-5 pcs | Standard unit price, factory quality evaluation |
| Small Batch | 50-100 pcs | 8% volume discount + free fumigation pallet |
| Medium Bulk | 100-300 pcs | 15% discount + priority production scheduling |
| Container Load | 300+ pcs | Best ex-factory price + quarterly loyalty rebate |
Send us your required quantity, destination port, and WhatsApp/Email. Our export team responds within 24 hours with the best factory-direct wholesale pricing. We support long-term supply for overseas auto parts distributors, fleet maintenance companies, and heavy-duty truck repair networks worldwide.
