| Brand Name: | SHACMAN |
| MOQ: | 1 |
| Price: | Negotiable |
| Delivery Time: | 35-55days |
| Parameter | 10m³ Model | 12m³ Model |
|---|---|---|
| Wheelbase (mm) | 4600 | 4375+1400 |
| Length x Width x Height (mm) | 8025x2490x(327030) | 9700x2490x(327030) |
| Front Overhang (mm) | 1525 | 1525 |
| Rear Overhang (mm) | 1900 | 2400 |
| Approach Angle (°) | 25 | 25 |
| Departure Angle (°) | 25 | 19 |
| Track (mm) | 2062/1868 | 2062/1868 |
| Frame Ground Clearance (Empty) (mm) | 1115 +20 | 1090±20 |
| Minimum Turning Radius (mm) | 880 | 10208 |
| Minimum Ground Clearance (mm) | 315 | 315 |
| Loading Capacity | 10 | 20 |
| Chassis Curb Weight (kg) | 6760 | 9400 |
| Frame Dimensions (mm) | 300x80x(8+5) | 300x80x(8+5) |
| Frame Total Width (mm) | 850 | 850 |
| Front Leaf Spring Count | 10 | 10 |
| Rear Leaf Spring Count | 9+6 | 12 |
| Tire Model | 12.00R20 | 12.00R20 |
